| ブランド名: | Hongsinn |
| モデル番号: | HS-344 |
| MOQ: | 1 個/個 |
| 価格: | USD,0.78-7.59,Piece/Pieces |
| 支払条件: | L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム |
| 補給能力: | 5000、個/個、月 |
As a specialized manufacturer of high-precision CNC-machined components, we have dedicated ourselves to mastering the manufacturing challenges associated with large-format, thin-walled precision disk-type parts. This precision indexing baseplate is specifically engineered for use in semiconductor vacuum chambers and high-end automated indexing systems.
By employing unique machining stress control techniques, we ensure that—despite its exceptionally large diameter—the product maintains micron-level flatness and positional tolerances. Leveraging 20 years of experience in precision component manufacturing, we are capable of processing a wide range of high-performance materials—including aerospace-grade aluminum (7075-T6) and stainless steel (316L)—thereby enabling your equipment to achieve superior operational precision.
Large-diameter, thin-walled disk components are particularly susceptible to machining-induced deformation. We utilize advanced artificial aging and stress-relief machining processes—combined with vacuum-assisted fixturing techniques—to ensure that the product maintains outstanding flatness and geometric stability throughout its entire lifecycle.
Leveraging 4-axis and 5-axis CNC machining centers, we complete the simultaneous machining of all precision holes and slots in a single fixturing setup. Positional tolerances are consistently controlled within ±0.01mm, ensuring a perfect fit with your precision sensors or locating pins.
We offer a variety of surface treatment solutions, including hard anodizing, electroless nickel plating, and precision grinding. Our products meet strict cleanroom standards, featuring extremely low outgassing rates and exceptional corrosion resistance.
Every baseplate undergoes 100% inspection using a ZEISS Coordinate Measuring Machine (CMM). Unique position codes marked on the surface of each part ensure precise interchangeability and full data traceability within large-scale precision systems.
| Machining Equipment | 15 CNC Tapping Center, 18 CNC Lathes, 25 auto lathe, 4 MAZAK five axis CNC, etc. |
| Processing | Turning, Milling, Drilling, Tapping, Knurling, Wire EDM, Grinding, Engraving, Knurling, etc. |
| Tolerance | ±0.005mm |
| Material Workable | Copper, Steel, Aluminum, Brass, Stainless Steel, Titanium, Plastics (PEEK, ABS, Acrylic, Delrin, PP, PMMA, PC, POM, polyethylene, PVC, Nylon), Organic Glass, Carbon Fiber, Wood, etc. Other materials your requested. |
| Surface Treatment | Nickel Plating, Anodizing, Chrome Plating, Brushing, Polishing, Blacken, Powder coating, Sandblasting, de-burring, Electrophoresis, Passivation, etc. |
| Drawing Format | JPEG, PDF, DWG, DXF, IGS, STEP, CAD |
| MOQ | No MOQ Required, 1 PC is fine for us. |
| Lead Time | 1-30 days accordingly to your orders. |
| Quality System | 100% inspection before shipment, (CMM, Projector, Gauge and other inspection tools) |
| Size | Customization |
| Standard | OEM/ODM |
| FOB Port | Shenzhen, China |
| Payment | 50% T/T in advance, 50% before shipment. Accept T/T L/C, Escrow, PayPal, Western Union |
| Packing | Carton box, wooden case, pallet, etc. |
| Shipping | By sea, by air, by DHL, UPS, FedEx, TNT or EMS, etc. |
