Aluminum Milling and Metal Milling Services in China

ブランド名:	HS
モデル番号:	HS-45
MOQ:	1 個/個
価格:	USD,0.89-10.79,Piece/Pieces
支払条件:	L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム
補給能力:	5000、個/個、月

Detail Information

製品説明

Detail Information

起源の場所:

広東省

証明:

ISO9001，ISO14001

製品名:

機械加工部品

表面処理:

あなたの要求として陽極酸化、研磨、クロム

サービス:

OEM /ODM CNC 加工

適用先:

あらゆるOEM CNC機械加工部品

サンプル:

サンプル料金を支払う必要がある

許容範囲:

0.01～±0.005mm

プロセス:

CNC加工+バリ取り

特徴:

耐久性と高精度

色:

カスタマイズされた色

受渡し時間:

サンプル注文の場合は3〜5日、大量注文の場合は10〜15日後

パッケージの詳細:

内側が EPE フォームで外側がカートン、または内側が EPE フォームで外側が木製

供給の能力:

5000、個/個、月

ハイライト:

Aluminum CNC milling services

Metal milling parts China

Precision CNC milling aluminum

製品説明

In today's globally connected manufacturing ecosystem, metal milling services represent a critical pillar of industrial production, with aluminum milling services being among the most frequently requested capabilities. The process of milling aluminium and other metals has evolved from simple manual operations to sophisticated computer-controlled systems capable of producing complex components with micron-level precision.

Product Specifications

Product Name	High Precision CNC Machining Milling Turning Aluminum Parts
Machining Service	CNC Turning, CNC Milling, Precision CNC Machining, Laser Cutting, EDM, etc.
Material	Aluminum: AL6061, Al6063, AL6082, AL7075, AL5052, A380 etc. Stainless Steel: SS201, SS301, SS303, SS304, SS316, SS416 etc. Steel: mild steel, Carbon steel, 4140, 4340, Q235, Q345B, 20#, 45# etc. Brass: HPb63, HPb62, HPb61, HPb59, H59, H68, H80, H90 etc. Copper: C11000, C12000, C36000 etc. Iron: A36, 45#, 1213, 12L14, 1215 etc. Plastic: ABS, PC, PE, POM, Delrin, Nylon, PP, PEI, Peek etc.
Capacity	CNC Turning: φ0.5 - φ300 * 750 mm, Tolerance: ±0.005 mm CNC Milling: 510 * 1020 * 500 mm (max), Tolerance: ±0.01 mm
Main Equipment	CNC Lathe, Machining Center, Milling Machine, CNC Laser Cutting Machine, Cylindrical Grinder Machine, Drilling Machine, etc.
Testing Equipment	Measurement instrument, Projector, CMM, Altimeter, Micrometer, Thread Gages, Calipers, Pin Gauge etc.
Inspection	100% QC, can provide inspection every batch
Drawing	3D Drawing: .step / .stp, 2D Drawing: .dxf / .dwg / .pdf

Mill-Turn Composite Machine Features

Comprehensive Functionality

Mill-turn composite machines perfectly combine CNC lathes and polygonal turning tools, offering both CNC turning and polygonal shaping/chip cutting capabilities. They can complete external turning, drilling, cutting, and multi-faceted turning in a single operation, thereby improving processing efficiency, ensuring high product concentricity, and fully leveraging the advantages of "one machine for multiple uses."

Rugged Structure

Mill-turn composite machines utilize a sand turning process with a bed and feet connection, equipped with imported roller-type linear guides and lead screws, ensuring excellent vibration resistance and strong cutting forces. This design can withstand high-intensity machining tasks, improving the machine's stability and durability.

Flexible Machining Capabilities

Mill-turn composite machines can achieve spindle positioning according to different products and can cut any polygon (such as triangles, quadrilaterals, pentagons, hexagons, heptagons, and other irregular shapes). Even without using the polygonal turning function, it can be used as a high-precision CNC lathe, meeting various machining needs.

Milling Design Considerations

Leverage CNC Precision: Utilize the high precision of CNC milling machines to rationally design part shapes and dimensions, ensuring high-quality and consistent machining.
Avoid Deep Pockets: Minimize deep pocket designs as machining sharp internal corners is often difficult. Consider using fillets to simplify the machining process.
Chamfer Top Edges: Chamfering reduces sharpness, improves appearance, and prevents hand injuries or accidental damage.
Add Filters to Pocket Bottom: Adding filter structures to pocket bottoms helps reduce stress concentration under load, thereby minimizing breakage risk.
Use Thin-Walled Structures with Caution: Thin-walled and fragile shapes may struggle to withstand cutting pressure during machining and should be designed carefully.
Avoid Complex Curves: When designing shapes, try to avoid complex curves on multiple axes, as maintaining these shapes during machining can be challenging.

Our Services

Ordering High-Precision Aluminum Parts: Our professional team and advanced equipment can meet your requirements for high-precision aluminum components.
100% Quality Guaranteed Products: We are committed to providing products that meet the highest standards, ensuring every part undergoes rigorous quality testing.
One-Stop Service: We offer comprehensive services from design to manufacturing, providing a complete solution to meet your needs.
Comprehensive After-Sales Support: To ensure your satisfaction, we provide extensive after-sales support to resolve any questions or problems during use.

Frequently Asked Questions

Are you a trading company or manufacturer?

We are a factory.

How can I obtain a quotation?

To receive a quotation, please send us drawings in formats such as IGS, DWG, STEP, etc., along with a detailed PDF. If you have any specific requirements, please include them in the request, and we will provide professional advice for your reference.

What if I don't have a drawing?

In such cases, you can provide us with samples or drawings. Rest assured, we will ensure the safety and confidentiality of any provided drawings.

What is your delivery time?

Normally, it takes 7-14 days for the parts to be ready. We have systems in place to ensure timely delivery.

How do you ship the products? What are the packing details?

For small quantity orders, we have partnerships with courier services like TNT, FEDEX, UPS, etc. For larger quantities, air or sea shipment options are available. We have standard packing details, but if you have any specific requirements, we are willing to assist you.

Do you provide samples? Is there an extra charge?

Yes, we can provide samples, but there may be an extra charge for them.

What are your payment terms? How can I make the payment?

Our payment terms are 50% T/T (bank transfer) in advance, with the balance payment due before shipment. If you have any other questions, please feel free to contact us.
